Setup & assembly
Your bike ships about 85% assembled. Plan on 30–45 minutes with the included tools.
Torque specs

BoltN·m
Battery Rail Bolts
2.5
Motor Mount Bolts
10–12.5
Seatpost Clamp
4–5
Rear Thru Axle
10
Carbon parts: always use a torque wrench and carbon assembly paste. Component makers' printed specs take priority.
Replacement parts
Geometry
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Top Tube | 590.0 | 614.0 | 637.0 | 660.0 |
| Seat Tube | 400.0 | 440.0 | 460.0 | 480.0 |
| Chainstay | 450.0 | 450.0 | 450.0 | 450.0 |
| Head Angle | 67.0° | 67.0° | 67.0° | 67.0° |
| Seat Angle | 75.0° | 75.0° | 75.0° | 75.0° |
| Head Tube | 90.0 | 100.0 | 120.0 | 130.0 |
| Bottom Bracket Height | 325.0 | 325.0 | 325.0 | 325.0 |
| Bottom Bracket Drop | 65.0 | 65.0 | 65.0 | 65.0 |
| Wheelbase | 1156.9 | 1184.1 | 1208.3 | 1232.6 |
| Fork Offset | 51.0 | 51.0 | 51.0 | 51.0 |
| Standover Height | 700.0 | 750.0 | 770.0 | 780.0 |
| Stack | 598.0 | 615.0 | 625.0 | 635.0 |
| Reach | 430.0 | 450.0 | 470.0 | 490.0 |
Frame specifications
FrameExplorer Peak
Wheel Size26 Fat, 27.5 Fat
MaterialCarbon
Front TravelRigid fork or 100-140mm
Max Fork Length140mm
Tire Compatibility26x5, 27.5x4.5
Rear Dropout197mm
Rear Axle224x12xP1.0mm, 13mm minimum thread length
Rear Brake Mount180 Post Mount
Bottom BracketShimano Drive Unit
Seatpost Diameter31.6mm
Seatpost Clamp Diameter34.9mm
Dropper RoutingInternal
Headset StandardZS56/28.6 | ZS56/40
Max Chainring34T round
Bashguard MountShimano Drive Unit Specific
