Setup & assembly
Your bike ships about 85% assembled. Plan on 30–45 minutes with the included tools.
Torque specs

BoltN·m
Seatpost Collar
4–5
Dropouts
5 (add Loctite upon reinstallation)
Rear Thru Axle
10
Carbon parts: always use a torque wrench and carbon assembly paste. Component makers' printed specs take priority.
Geometry
| Measurement | 26 | 27.5 |
|---|---|---|
| Top Tube | 584.0 | 600.0 |
| Seat Tube | 300.0 | 320.0 |
| Chainstay | 385.0 | 395.0 |
| Head Angle | 69.0 | 68.0 |
| Seat Angle | 73.0 | 75.0 |
| Head Tube | 120.0 | 120.0 |
| Bottom Bracket Height | 318.0 | 313.0 |
| Bottom Bracket Drop | 22.5 | 42.0 |
| Stack | 569.0 | 595.7 |
| Reach | 410.0 | 440.0 |
| Axle to Crown | 480.0 | 492.0 |
Frame specifications
Frame801
Wheel Size26"
27.5"
27.5"
MaterialAluminum
Front Travel100mm
Tire Compatibility26": 26x2.4
27.5": 27.5x2.4
27.5": 27.5x2.4
Rear Dropout26": 10x135 Sliding Dropouts
27.5": Boost 148 Thru-Axle Sliding Dropouts
27.5": Boost 148 Thru-Axle Sliding Dropouts
Rear Axle27.5": 164mm M12xP1.5x15mm
Rear Brake Mount160mm post
Bottom Bracket73mm BSA
Seatpost Diameter27.2mm
Seatpost Clamp Diameter31.8mm
Dropper RoutingNo
Headset StandardZS44/ZS56
